Slim surface movement detector AC220-240V
€7.09
Quantity
Extraplano surface motion detector with high sensitivity. This sensor uses infrared as a source of activation. Adjustable in time and luminous, with twilight detector and incorporates a hyportizer at least 5 seconds up to 7 minutes. 360º detection range and a distance of 6m. Power load: Max. 2000W (incandescent). 500W (LED.)
Surface Movement Detector that allows you to adjust the time on, Range of detention and light sensitivity. It has a 360º coverage angle and a detection field up to 6 meters.
The output and input voltage covers a range of between 220-240V.
Use infrared as activation source When entered into the detection field, it has a twilight detector incorporated. The detector is capable of capturing infrared emissions from any heat source without emitting any type of radiation.
It is activated when a heat source moves in front of the switch. In the same way, the device is deactivated once the device stops capturing heat. Integrate a timer with the possibility of changing 5 seconds to 7 minutes.
It incorporates the screws necessary for assembly. Ideal for lighting automatic for luminaires in corridors, stairs, bathrooms, testers, etc ... G2 year arative
| REFERENCE | 8059 |
|---|---|
| Nominal power | Max. 2000W (incandescent). 500W (LED) |
| Nominal voltage | 220v-240v |
| Construction material | Fire-retardant thermoplastic |
| Angle opening (º) | 360 ° |
| Certificates | CE - RoHS |
| Estimated Life LED Diode (H) | 30.000 |
| Measures (mm) | Ø 62.5 * 55 * 26.5 |
| Work frequency (Hz) | 50 / 60hz |
| Temperature range (ºC) | -20 ° C ~ + 55 ° C |
| Lit cycles | 100.000 |
| Start time (s) | 0,2s |
| Additional information | 6 m. |
| Control modes | INFRARED |
| Guarantee years | 2 |
